FWF-40F-EFortinet FortiWifi 40F
List PriceThe Fortinet FortiWifi 40F is the wireless-equipped sibling of the FortiGate 40F: the same compact, fanless desktop next-generation firewall with secure SD-WAN, plus a built-in single-radio (2.4 GHz / 5 GHz) 802.11a/b/g/n/ac Wave 2 access point. System-on-a-chip acceleration delivers 5 Gbps of firewall throughput, 1 Gbps of IPS and 600 Mbps of full threat protection, so a small site gets firewall, SD-WAN and Wi-Fi from one box.
It carries five GE RJ45 ports — 1 WAN, 3 internal and 1 FortiLink — plus a USB port that accepts a compatible third-party 3G/4G modem for extra WAN connectivity or a redundant link. The built-in radio runs 3x3 MU-MIMO at up to 1300 Mbps on 5 GHz or 450 Mbps on 2.4 GHz.
Designed for small environments, it sits on a desk or wall-mounts, and it is fanless and silent. The FortiLink port lets a FortiSwitch join the unit as a logical extension of the firewall, with those ports reconfigurable as regular ports if not needed.
Key features
- Built-in Wi-Fi — single radio, 2.4 GHz / 5 GHz, 802.11a/b/g/n/ac Wave 2, 3x3 MU-MIMO
- 5 Gbps firewall throughput, 1 Gbps IPS, 800 Mbps NGFW, 600 Mbps threat protection
- 5× GE RJ45 ports — 1 WAN, 3 internal, 1 FortiLink
- Up to 1300 Mbps wireless on 5 GHz, 450 Mbps on 2.4 GHz
- USB port for 3G/4G — redundant or additional WAN link
- IPsec VPN at 4.4 Gbps — 200 gateway-to-gateway and 250 client-to-gateway tunnels
- 700,000 concurrent sessions, 35,000 new sessions/second
- Fanless, 0 dBA desktop unit, 1 kg
Works with
Frequently asked questions
Hardware only or a bundle?
Hardware only includes the appliance; the FortiGuard security services that power IPS, web filtering and threat protection are subscriptions. The bundles pair the hardware with FortiCare Premium support plus either Unified Threat Protection (UTP) or Enterprise Protection for 1, 3 or 5 years — usually the simpler and cheaper way to buy the first term.
How does this differ from the wired FortiGate 40F?
Same appliance and the same firewall performance figures, with one addition: a built-in single radio (2.4 GHz / 5 GHz, 802.11a/b/g/n/ac Wave 2) access point, so a small site needs no separate AP. The wired FortiGate 40F has no wireless interface.
Is the FortiWifi 40F big enough for my site?
It suits small branches: 5 Gbps of raw firewall throughput but 600 Mbps of full threat protection, which is the realistic ceiling with all inspection on. If the site's internet connection is near or above that, step up to the FortiWifi 60F (10 Gbps firewall, 700 Mbps threat protection).
Sizing a FortiGate deployment? Call 0333 242 1314 or email sales@clisecure.com.
Interfaces and Modules
| GE RJ45 WAN / DMZ Ports | 1 |
|---|---|
| GE RJ45 Internal Ports | 3 |
| GE RJ45 FortiLink Ports | 1 |
| Wireless Interface | Single Radio (2.4GHz/5GHz) 802.11 a/b/g/n/ac-W2 |
| USB Ports | 1 |
| Console (RJ45) | 1 |
Radio Specifications
| Multiple (MU) MIMO | 3 x 3 |
|---|---|
| Maximum Wi-Fi Speeds | 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Maximum Tx Power | 20 dBm |
| Antenna Gain | 3.5 dBi @ 5GHz, 5 dBi @ 2.4 GHz |
System Performance — Enterprise Traffic Mix
| IPS Throughput | 1 Gbps |
|---|---|
| NGFW Throughput | 800 Mbps |
| Threat Protection Throughput | 600 Mbps |
System Performance
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 5/5/5 Gbps |
|---|---|
| Firewall Latency (64 byte UDP packets) | 2.97 μs |
| Firewall Throughput (Packets Per Second) | 7.5 Mpps |
| Concurrent Sessions (TCP) | 700,000 |
| New Sessions/Second (TCP) | 35,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 4.4 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL-VPN Throughput | 490 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 310 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 320 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55,000 |
| Application Control Throughput (HTTP 64K) | 990 Mbps |
| CAPWAP Throughput (HTTP 64K) | 3.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 8 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 16 / 8 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active / Active, Active / Passive, Clustering |
Dimensions
| Height x Width x Length (inches) | 1.5 x 8.5 x 6.3 |
|---|---|
| Height x Width x Length (mm) | 38.5 x 216 x 160 |
| Weight | 2.2 lbs (1 kg) |
| Form Factor | Desktop |
| Input rating | 12Vdc, 3A |
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
| Power Consumption (Average / Maximum) | 14.6 W / 16.6 W |
| Maximum Current | 100V AC / 0.2A, 240V AC / 0.1A |
| Heat Dissipation | 56.64 BTU/hr |
Operating Environment and Certifications
| Operating Temperature | 32–104°F (0–40°C) |
|---|---|
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fanless 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
Product details
| Brand | Fortinet |
|---|---|
| Part number | FWF-40F-E |
Interfaces and Modules
| GE RJ45 WAN / DMZ Ports | 1 |
|---|---|
| GE RJ45 Internal Ports | 3 |
| GE RJ45 FortiLink Ports | 1 |
| Wireless Interface | Single Radio (2.4GHz/5GHz) 802.11 a/b/g/n/ac-W2 |
| USB Ports | 1 |
| Console (RJ45) | 1 |
Radio Specifications
| Multiple (MU) MIMO | 3 x 3 |
|---|---|
| Maximum Wi-Fi Speeds | 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Maximum Tx Power | 20 dBm |
| Antenna Gain | 3.5 dBi @ 5GHz, 5 dBi @ 2.4 GHz |
System Performance — Enterprise Traffic Mix
| IPS Throughput | 1 Gbps |
|---|---|
| NGFW Throughput | 800 Mbps |
| Threat Protection Throughput | 600 Mbps |
System Performance
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 5/5/5 Gbps |
|---|---|
| Firewall Latency (64 byte UDP packets) | 2.97 μs |
| Firewall Throughput (Packets Per Second) | 7.5 Mpps |
| Concurrent Sessions (TCP) | 700,000 |
| New Sessions/Second (TCP) | 35,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 4.4 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL-VPN Throughput | 490 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 310 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 320 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55,000 |
| Application Control Throughput (HTTP 64K) | 990 Mbps |
| CAPWAP Throughput (HTTP 64K) | 3.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 8 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 16 / 8 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active / Active, Active / Passive, Clustering |
Dimensions
| Height x Width x Length (inches) | 1.5 x 8.5 x 6.3 |
|---|---|
| Height x Width x Length (mm) | 38.5 x 216 x 160 |
| Weight | 2.2 lbs (1 kg) |
| Form Factor | Desktop |
| Input rating | 12Vdc, 3A |
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
| Power Consumption (Average / Maximum) | 14.6 W / 16.6 W |
| Maximum Current | 100V AC / 0.2A, 240V AC / 0.1A |
| Heat Dissipation | 56.64 BTU/hr |
Operating Environment and Certifications
| Operating Temperature | 32–104°F (0–40°C) |
|---|---|
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fanless 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
Product details
| Brand | Fortinet |
|---|---|
| Part number | FWF-40F-E |
