Fortinet
FWF-60F-EFortinet FortiWifi 60F
List PriceThe Fortinet FortiWifi 60F is the wireless-equipped sibling of the FortiGate 60F: a compact, fanless desktop next-generation firewall with secure SD-WAN, plus a built-in single-radio (2.4 GHz / 5 GHz) 802.11a/b/g/n/ac Wave 2 access point. System-on-a-chip acceleration delivers 10 Gbps of firewall throughput, 1.4 Gbps of IPS and 700 Mbps of full threat protection.
It carries ten GE RJ45 ports — 2 WAN, 1 DMZ, 5 internal and 2 FortiLink — plus a USB port that accepts a compatible third-party 3G/4G modem for extra WAN connectivity or a redundant link. The built-in radio runs 3x3 MU-MIMO at up to 1300 Mbps on 5 GHz or 450 Mbps on 2.4 GHz.
Designed for small environments, it sits on a desk or wall-mounts, and it is fanless and silent. The two FortiLink ports let FortiSwitches join the unit as a logical extension of the firewall, reconfigurable as regular ports if not needed.
Key features
- Built-in Wi-Fi — single radio, 2.4 GHz / 5 GHz, 802.11a/b/g/n/ac Wave 2, 3x3 MU-MIMO
- 10 Gbps firewall throughput, 1.4 Gbps IPS, 1 Gbps NGFW, 700 Mbps threat protection
- 10× GE RJ45 ports — 2 WAN, 1 DMZ, 5 internal, 2 FortiLink
- Up to 1300 Mbps wireless on 5 GHz, 450 Mbps on 2.4 GHz
- IPsec VPN at 6.5 Gbps — 200 gateway-to-gateway and 500 client-to-gateway tunnels
- 700,000 concurrent sessions, 35,000 new sessions/second
- Manages up to 16 FortiSwitches and 64 FortiAPs
- Fanless, 0 dBA desktop unit, 1.01 kg
Works with
Frequently asked questions
Hardware only or a bundle?
Hardware only includes the appliance; the FortiGuard security services that power IPS, web filtering and threat protection are subscriptions. The bundles pair the hardware with FortiCare Premium support plus either Unified Threat Protection (UTP) or Enterprise Protection for 1, 3 or 5 years — usually the simpler and cheaper way to buy the first term.
How does this differ from the wired FortiGate 60F?
Same appliance and the same firewall performance figures, with one addition: a built-in single radio (2.4 GHz / 5 GHz, 802.11a/b/g/n/ac Wave 2) access point, so a small site needs no separate AP. The wired FortiGate 60F has no wireless interface. Unlike the FortiWifi 61F, this 60F variant has no onboard SSD storage.
Is the FortiWifi 60F big enough for my site?
It suits growing branch sites: 10 Gbps of raw firewall throughput but 700 Mbps of full threat protection, which is the realistic ceiling with all inspection on. If the site needs onboard log storage as well as Wi-Fi, the FortiWifi 61F adds a 128 GB SSD on the same platform.
Sizing a FortiGate deployment? Call 0333 242 1314 or email sales@clisecure.com.
Hardware Specifications
| GE RJ45 WAN / DMZ Ports | 2 / 1 |
|---|---|
| GE RJ45 Internal Ports | 5 |
| GE RJ45 FortiLink Ports (Default) | 2 |
| Wireless Interface | Single Radio (2.4GHz/5GHz), 802.11 a/b/g/n/ac-W2 |
| USB Ports | 1 |
| Console (RJ45) | 1 |
| Internal Storage | – |
Radio Specifications
| Multiple User (MU) MIMO | 3x3 |
|---|---|
| Maximum Wi-Fi Speeds | 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Maximum Tx Power | 20 dBm |
| Antenna Gain | 3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz |
System Performance — Enterprise Traffic Mix
| IPS Throughput | 1.4 Gbps |
|---|---|
| NGFW Throughput | 1 Gbps |
| Threat Protection Throughput | 700 Mbps |
System Performance
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 10/10/6 Gbps |
|---|---|
| Firewall Latency (64 byte UDP packets) | 3.3 μs |
| Firewall Throughput (Packets Per Second) | 9 Mpps |
| Concurrent Sessions (TCP) | 700,000 |
| New Sessions/Second (TCP) | 35,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 6.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL-VPN Throughput | 900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 630 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 400 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55,000 |
| Application Control Throughput (HTTP 64K) | 1.8 Gbps |
| CAPWAP Throughput (HTTP 64K) | 8 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 16 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 64 / 32 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
Dimensions
| Height x Width x Length (inches) | 1.5 x 8.5 x 6.3 |
|---|---|
| Height x Width x Length (mm) | 38.5 x 216 x 160 mm |
| Weight | 2.23 lbs (1.01 kg) |
| Form Factor | Desktop |
Operating Environment and Certifications
| Power Rating | 12Vdc, 3A |
|---|---|
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
| Maximum Current | 100Vac/1.0A, 240Vac/0.6A |
| Power Consumption (Average / Maximum) | 17.2 W / 18.7 W |
| Heat Dissipation | 63.8 BTU/hr |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fanless 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
Product details
| Brand | Fortinet |
|---|---|
| Part number | FWF-60F-E |
Hardware Specifications
| GE RJ45 WAN / DMZ Ports | 2 / 1 |
|---|---|
| GE RJ45 Internal Ports | 5 |
| GE RJ45 FortiLink Ports (Default) | 2 |
| Wireless Interface | Single Radio (2.4GHz/5GHz), 802.11 a/b/g/n/ac-W2 |
| USB Ports | 1 |
| Console (RJ45) | 1 |
| Internal Storage | – |
Radio Specifications
| Multiple User (MU) MIMO | 3x3 |
|---|---|
| Maximum Wi-Fi Speeds | 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Maximum Tx Power | 20 dBm |
| Antenna Gain | 3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz |
System Performance — Enterprise Traffic Mix
| IPS Throughput | 1.4 Gbps |
|---|---|
| NGFW Throughput | 1 Gbps |
| Threat Protection Throughput | 700 Mbps |
System Performance
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 10/10/6 Gbps |
|---|---|
| Firewall Latency (64 byte UDP packets) | 3.3 μs |
| Firewall Throughput (Packets Per Second) | 9 Mpps |
| Concurrent Sessions (TCP) | 700,000 |
| New Sessions/Second (TCP) | 35,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 6.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 500 |
| SSL-VPN Throughput | 900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 200 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 630 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 400 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 55,000 |
| Application Control Throughput (HTTP 64K) | 1.8 Gbps |
| CAPWAP Throughput (HTTP 64K) | 8 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 16 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 64 / 32 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
Dimensions
| Height x Width x Length (inches) | 1.5 x 8.5 x 6.3 |
|---|---|
| Height x Width x Length (mm) | 38.5 x 216 x 160 mm |
| Weight | 2.23 lbs (1.01 kg) |
| Form Factor | Desktop |
Operating Environment and Certifications
| Power Rating | 12Vdc, 3A |
|---|---|
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz |
| Maximum Current | 100Vac/1.0A, 240Vac/0.6A |
| Power Consumption (Average / Maximum) | 17.2 W / 18.7 W |
| Heat Dissipation | 63.8 BTU/hr |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fanless 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
Product details
| Brand | Fortinet |
|---|---|
| Part number | FWF-60F-E |
