Fortinet FEX-511F

Fortinet FortiExtender 511F

List Price

Exc VAT £97.70 - £976.98

Inc VAT £117.24 - £1,172.38

In stock

Bundle

Quantity

Request a Quotation

Trade pricing on every quotation — response within one working day.

Buying for a project? Volume pricing and stock allocation 0333 242 1314 · sales@clisecure.com Get a quote

PDF Manufacturer datasheet Full technical specifications

CELLULAR STANDARD5G Sub-6GHz / LTE

SIM SLOTSDual SIM (1x internal modem)

WAN/LAN INTERFACES5x GbE RJ45 + 1x GbE SFP

FORM FACTOR/MOUNTINGIndoor — Wall Mount / Desktop

The Fortinet FortiExtender 511F brings 5G Sub-6GHz cellular to the FortiExtender range, using a Dual SIM 5G M.2 module (Quectel RM-502Q-AE) with 2x2 and 4x4 MIMO to deliver industry-leading data speeds for branch offices and other bandwidth-hungry remote sites.

Integration with FortiGate appliances gives a single pane of glass for managing both the wired and wireless WAN connections and their security, reducing the total cost of ownership for branch WAN and simplifying remote-site management.

It can be located indoors or outdoors up to 100m from the FortiGate appliance or network switch, and is managed either directly from the FortiGate or hosted via FortiExtender Cloud, which supports an unlimited number of units worldwide.

Key features

Internal Dual SIM 5G Sub-6GHz modem (Quectel RM-502Q-AE) with NSA and SA support
2x2 and 4x4 MIMO on both 5G and LTE for industry-leading data speeds
5x GbE RJ45 ports plus 1x GbE SFP port
Powered over Ethernet via 802.3at PoE (25.5W)
4x all-in-one 5G/LTE/GNSS antennas with receiver diversity and equalization
Dual-SIM support with intelligent fail-over, carrier-certified for Verizon, AT&T and T-Mobile
Managed from the FortiGate directly, or hosted via FortiExtender Cloud

Works with

Frequently asked questions

What is the FortiExtender 511F used for?

It's a 5G/LTE cellular WAN extender for branch offices, giving a high-bandwidth wireless link that can serve as the primary WAN connection or as SD-WAN failover behind a FortiGate.

What cellular bands and SIM support does it have?

A single Quectel RM-502Q-AE modem with dual-SIM support and intelligent fail-over, covering 5G Sub-6 bands n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79 plus 3G UMTS/HSPA+/WCDMA bands B1–B8/B19, and carrier-certified for Verizon, AT&T and T-Mobile.

What support and licensing options are available?

FortiCare Premium support (1, 3 or 5 years) and FortiExtender-Cloud License and Support (1, 3 or 5 years, covering FortiExtender 300–500 series and dual-modem models) are both available for the 511F.

Sizing a network deployment? Call 0333 242 1314 or email sales@clisecure.com.

Hardware and System

Modem Support	Internal (1x Modem)
Number of Antennas	4x 5G/LTE/GNSS All-in-One Antennas
Power over Ethernet (PoE) Powered	IEEE 802.3at (25.5 W)
Ethernet Ports	5 GE RJ45 Ports, 1 GE SFP Port
GPS Antenna Port	Yes
Mounting Options	Wall Mount / Desktop
Type	Indoor
Bluetooth	Maximum Transmit Power 10 dBm Frequency 2.4 GHz

Dimensions

Height x Width x Length (inches)	1.77 x 7.09 x 7.09 (not including antenna length)
Height x Width x Length (mm)	45 x 180 x 180 (not including antenna length)
Weight	1.1 lbs (0.5 kg)

Environment

Power Consumption (Max)	10 W
Storage Temperature	-4–158°F (-20–70°C)
Humidity	5–95%

Certifications

IC	ICES-003, RSS-247, RSS-102
CB	(IEC/EN 60950-1, IEC/EN 62368-1)
UL	(UL/CSA 60950-1, UL/CSA 62368-1)
FCC	FCC Part 15 Subpart B and ICES-003
CE	EMC 2014/30/EU (EN 55032, EN 55024, EN 55035, EN 61000-3-2/-3; EN 301 489-1/-17/-19, Draft EN 301 489-52) RED 2014/53/EU (EN 300 328, EN 303 413, EN 301 908-1/-2/-13, EN 62311, EN 50382, EN 50665, EN 50663, EN 62479) LVD 2014/35/EU (EN 60950-1, EN 62368-1)

Regional Compatibility

Region	Global Carriers

Internal Modem Specifications

Modem Model	Quectel RM-502Q-AE
5G NR SA and NSA	5G Sub-6 Bands: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48/n66/n71/n77/n78/n79
3G: UMTS/HSPA+	Bands: B1/B2/B3/B4/B5/B6/B8/B19
3G: WCDMA	Bands: B1/B2/B3/B4/B5/B6/B8/B19
Additional Ports	MIMO1, MIMO2
Connector Type	4x SMA (MAIN, MIMO1, MIMO2, Diversity/GPS)
Module Certifications	GCF (Global), CE (Europe), PTCRB (North America), FCC (America), IC (Canada), JATE/TELEC (Japan), RCM (Australia/New Zealand)
Diversity	Yes
MIMO	Yes
GNSS Bias	Yes
XLTE (band bonding)	Yes

Advanced Radio Technology

2x2 MIMO	Enables industry leading data speeds
4x4 MIMO	Enables industry leading data speeds
5G Downlink 4x4 MIMO bands	n1/n2/n3/n7/n25/n38/n40/n41/n48/n66/n77/n78/n79
5G Uplink 2x2 MIMO Band	41
LTE Downlink 4x4 MIMO bands	B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66
Receiver Equalization	Improves performance in noisy and highly mobile environments
Receiver Diversity	Improves performance at cell edges and in buildings
Connection status / Auto-connect / Auto-select network	Yes
Data byte count / Network profile / Self-diagnostics	Yes
Power management	Standby & hibernate selective suspend
DIAG & AT Commands / Private IP SIM support	Yes
L2 and L3 Tunnel modes	Via VLAN and CAPWAP for fast and flexible deployments
Single pane of glass management	Via FortiGate and FortiManager
SIM Features	Dual-SIM support with intelligent fail-over algorithms. SIM Size: Micro-SIM type 3FF. SIM Security Cover. IMEI printed at bottom of enclosure for ease of activation
Carrier Certifications	Verizon, AT&T, PTCRB, T-Mobile

Product details

Brand	Fortinet
Part number	FEX-511F
