FC-10-X101M-247-02-12Fortinet FortiExtender 101F
List PriceThe Fortinet FortiExtender 101F is part of Fortinet's Security-driven networking approach to wireless WAN, giving organisations business continuity and improved network availability by securing connectivity across wired broadband and cellular networks — from point-of-sale systems to vehicle fleet communication.
Integration with a FortiGate provides single pane of glass management of the wired and wireless WAN connections and their security, reducing the total cost of ownership of the WAN and improving manageability of remote connections.
It can be sited indoors or outdoors, up to 100m from the FortiGate or network switch, to maximise 3G/4G LTE signal strength, and can be managed directly from the FortiGate or from FortiExtender Cloud, which offers hosted management of unlimited FortiExtenders worldwide.
Key features
- Internal Dual-SIM 3G/4G LTE CAT6 modem for North America carriers
- 5× GE RJ45 ports (WAN + LAN), including a PoE PD port
- 3× external SMA antennas plus a GPS/GNSS antenna port
- Powered over Ethernet — IEEE 802.3af/at (15.4W)
- Compact indoor wall-mount/desktop enclosure, 0.37 kg
Works with
- Part of The Fortinet range
- Pairs with a FortiGate firewall for single pane of glass management of wired and wireless WAN, or manages via FortiExtender Cloud
Frequently asked questions
What is the FortiExtender 101F for?
It's a 3G/4G LTE wireless WAN extender that provides reliable broadband connectivity for branch offices and remote devices, secured and managed through the Fortinet Security Fabric via a connected FortiGate.
Does it support dual-SIM?
Yes — the hardware description confirms a Dual SIM 3G/4G LTE CAT6 M.2 module for North America carriers, with GPS/GNSS support via the external antenna port.
What FortiCare and cloud options are available?
1 year FortiCare Premium Support is available, alongside FortiExtender Cloud License and Support in 1, 3 and 5 year terms for centralised hosted management.
Sizing a network deployment? Call 0333 242 1314 or email sales@clisecure.com.
Hardware and System
| Modem Support | Internal (1x Modem) |
|---|---|
| Number of Antennas | 3 SMA External |
| Power over Ethernet (PoE) Powered | IEEE 802.3af (15.4 W) |
| Ethernet Ports | 5 GE RJ45 Ports (WAN + LAN) |
| Bluetooth | N/A |
| GPS Antenna Port | Yes |
| Mounting Options | Wall Mount / Desktop |
| Type | Indoor |
Dimensions
| Height x Width x Length (inches) | 1.45 x 5.9 x 5.9 (not including antenna length) |
|---|---|
| Height x Width x Length (mm) | 37 x 150 x 150 (not including antenna length) |
| Weight | 0.81 lbs (0.37 kg) |
Environment
| Power Required | 12V/2A External Adapter/PoE(af/at) |
|---|---|
| Power Consumption (Average) | 6.5 W |
| Power Consumption (Maximum) | 8.5 W |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -4–158°F (-20–70°C) |
| Humidity | 5–95% |
Certifications
| FCC | FCC Part 15B, 2.1091 |
|---|---|
| IC | ICES-003, RSS-102 |
| CE | — |
| UL | UL/CSA 62368-1 |
| CB | IEC/EN 60950-1, IEC/EN 62368-1 |
Regional Compatibility and Internal Modem Specifications
| Regional Compatibility | North America Carriers |
|---|---|
| Modem Model | Quectel EM06-A (1x Modem) |
| 3G: UMTS/HSPA+ | Bands: B2/B4/B5 |
| 3G: WCDMA | Bands: B2/B4/B5 |
| Additional Ports | GPS antenna port |
| Connector Type | SMA (MAIN, AUX, GPS) |
| Module Certifications | FCC, IC, GCF, PTCRB |
| Diversity | Yes |
| MIMO | Yes |
| GNSS Bias | Yes |
Product details
| Brand | Fortinet |
|---|---|
| Part number | FEX-101F-AM |
