FS-624FFortinet FortiSwitch 624F
List PriceThe Fortinet FortiSwitch 624F is a member of the FortiSwitch campus family, built to combine security, performance and manageability for enterprise campus networks that need reliable protection against threats. It carries 24x 1GE/2.5GE/5GE RJ45 ports plus 4x 10GE/25GE SFP+/SFP28 uplinks in a 1 RU rack-mount chassis with no PoE — for a PoE-capable version of the same switch, see the FortiSwitch 624F-FPOE.
The 624F is designed to be managed through FortiLink, Fortinet's proprietary protocol that links a FortiGate Next-Generation Firewall to FortiSwitch hardware. FortiLink turns the switch into a logical extension of the FortiGate, so network security and access-layer switching functions are both handled from a single interface, with centralized VLAN configuration, software upgrades and PoE control across every managed switch.
Through FortiLink, the 624F also gains basic Network Access Control (NAC) capability — profiling and securely onboarding devices as they connect, with automated segmentation and microsegmentation of IoT devices, quarantine for compromised endpoints, and virtual patching against emerging threats.
Key features
- 24x 1GE/2.5GE/5GE RJ45 ports plus 4x 10GE/25GE SFP+/SFP28 uplink ports
- 440 Gbps switching capacity (duplex) and 654 Mpps forwarding
- Dual hot-swappable 350W AC power supplies for redundancy
- 1 RU rack-mount chassis with dedicated 10/100/1000 management port and RJ-45 serial console port
- FortiLink integration with FortiGate for centralized switch, VLAN and PoE control across up to 300 switches per FortiGate (model dependent)
- 802.1x authentication, DHCP snooping, device detection and host quarantine when managed through FortiLink
- Limited lifetime hardware warranty on the switch itself
Works with
- FortiGate firewalls — for FortiLink-managed deployment
- The Fortinet range
Frequently asked questions
How is the FortiSwitch 624F managed?
Through FortiLink, connected to a FortiGate Next-Generation Firewall. This gives centralized VLAN configuration, software upgrades, PoE control, link aggregation and spanning tree management, LLDP/MED and IGMP snooping across all FortiLink-managed switches from a single console — with FortiGate handling Layer 3 routing, virtual domains and UTM features such as firewall, IPS, AV and application control on the switch's behalf.
What's the difference between FortiCare Premium and Elite support?
Both are paid support tiers for the 624F, available in 1, 3 or 5 year terms. Elite is priced above Premium at every term length, reflecting an enhanced service level; full SLA details are confirmed at quotation.
Does the 624F support PoE?
No — this model has no PoE ports. For Power over Ethernet on the same 24-port/4-uplink layout, choose the FortiSwitch 624F-FPOE, which adds 24x 802.3af/at/bt type 4 PoE ports with a 1440W power budget.
Sizing a network deployment? Call 0333 242 1314 or email sales@clisecure.com.
Hardware Specifications
| Total network interfaces | 24x 1GE/2.5GE/5GE RJ45 ports and 4x 10GE/25GE SFP+/SFP28 ports |
|---|---|
| Dedicated management port | 1x 10/100/1000 |
| RJ-45 serial console port | 1 |
| Form factor | 1 RU rack mount |
| Power over Ethernet (PoE) ports | None |
| Mean time between failures | > 10 years |
System Specifications
| Switching capacity (duplex) | 440 Gbps |
|---|---|
| Packets per second (duplex) | 654 Mpps |
| MAC address storage | 64 K |
| Network latency | < 1µs |
| VLANs supported | 4 K |
| Link aggregation group size | 28 |
| Total link aggregation groups | Up to number of ports |
| Packet buffers | 8 MB |
| Memory | 4GB DDR4 |
| Flash | 32 MB |
| Drive | 32G SSD |
| ACL | 36k |
| Spanning tree instances | 32 |
| Route entries (IPv4) | 16 k |
| Host entries (IPv4) | 192 k |
| Multicast route entries | 12 k |
Dimensions
| Height x depth x width (in) | 1.75 x 13.8 x 17.3 |
|---|---|
| Height x depth x width (mm) | 44 x 350 x 440 |
| Weight | 6.925 kg |
Environment
| Power required | 100–240V AC, 50/60 Hz |
|---|---|
| Power consumption (maximum) | 240 W |
| Power supply | 2x 350W |
| Redundant power | Dual hot-swappable AC |
| Heat dissipation | 423 BTU/h |
| Operating temperature | 32–113°F (0–45°C) |
| Storage temperature | -40–158°F (-40–70°C) |
| Humidity | 5–95% non-condensing |
| Air-flow direction | Front-to-back |
| Noise level | 54.88 dBA |
Certification and Compliance
| Certifications | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
|---|
Warranty
| Fortinet warranty | Limited lifetime* warranty on all models |
|---|
Product details
| Brand | Fortinet |
|---|---|
| Part number | FS-624F |
Hardware Specifications
| Total network interfaces | 24x 1GE/2.5GE/5GE RJ45 ports and 4x 10GE/25GE SFP+/SFP28 ports |
|---|---|
| Dedicated management port | 1x 10/100/1000 |
| RJ-45 serial console port | 1 |
| Form factor | 1 RU rack mount |
| Power over Ethernet (PoE) ports | None |
| Mean time between failures | > 10 years |
System Specifications
| Switching capacity (duplex) | 440 Gbps |
|---|---|
| Packets per second (duplex) | 654 Mpps |
| MAC address storage | 64 K |
| Network latency | < 1µs |
| VLANs supported | 4 K |
| Link aggregation group size | 28 |
| Total link aggregation groups | Up to number of ports |
| Packet buffers | 8 MB |
| Memory | 4GB DDR4 |
| Flash | 32 MB |
| Drive | 32G SSD |
| ACL | 36k |
| Spanning tree instances | 32 |
| Route entries (IPv4) | 16 k |
| Host entries (IPv4) | 192 k |
| Multicast route entries | 12 k |
Dimensions
| Height x depth x width (in) | 1.75 x 13.8 x 17.3 |
|---|---|
| Height x depth x width (mm) | 44 x 350 x 440 |
| Weight | 6.925 kg |
Environment
| Power required | 100–240V AC, 50/60 Hz |
|---|---|
| Power consumption (maximum) | 240 W |
| Power supply | 2x 350W |
| Redundant power | Dual hot-swappable AC |
| Heat dissipation | 423 BTU/h |
| Operating temperature | 32–113°F (0–45°C) |
| Storage temperature | -40–158°F (-40–70°C) |
| Humidity | 5–95% non-condensing |
| Air-flow direction | Front-to-back |
| Noise level | 54.88 dBA |
Certification and Compliance
| Certifications | FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2 |
|---|
Warranty
| Fortinet warranty | Limited lifetime* warranty on all models |
|---|
Product details
| Brand | Fortinet |
|---|---|
| Part number | FS-624F |
