Grandstream GSC3565 Smart Outdoor Video Intercom

The Grandstream GSC3565 is the video version of Grandstream's outdoor smart intercom range. It takes the same sealed, vandal-resistant panel as the audio-only GSC3560 and adds a 4-megapixel sensor streaming 1080p at 30fps, so whoever answers the call can see the caller as well as hear them.

A very wide 152-degree diagonal field of view captures the whole doorway rather than just a face-height crop, and 120 dB wide dynamic range keeps detail visible when a visitor is backlit by bright sky. Six auto-brightness white LEDs handle darkness. Entry can be granted from a SIP call, the SecureAccess app, a QR code or your own software via HTTP API, and two relay outputs — one of them an anti-magnetic solid state relay — drive the lock and any alarm linkage directly.

Key features

• 1080p video at 30fps — 1/3-inch 4MP CMOS sensor with HDR for a clear picture of the caller
• 152-degree diagonal field of view — sees the whole doorway, including children and anyone standing to one side
• 120 dB wide dynamic range — faces stay visible against bright sky or low winter sun
• Six auto-brightness white LEDs — usable images after dark without a separate light
• QR code entry — issue time-limited codes to contractors and visitors instead of keys or fobs
• IP66 and IK10 rated — impact protection extends across the metal surface, buttons and the lens area
• 10-watt speaker and dual mics — 90 dB intercom output and 6-metre speech pickup for noisy street-side doors
• Two relay outputs — lock control and alarm linkage, including an anti-magnetic solid state relay
• Single-cable install — IEEE 802.3at Class 4 PoE+, or local 12–48V DC power
• Encrypted and cloud managed — 256-bit AES, TLS, SRTP, plus GDMS and TR-069 remote provisioning

Technical specification

Camera and video

• 1/3-inch 4MP CMOS sensor with HDR support
• Resolution: 1920 x 1080 at 30fps
• Field of view: 127° horizontal, 70° vertical, 152° diagonal
• Wide dynamic range: up to 120 dB
• Illumination: 6 white LEDs with auto-brightness

Audio

• Dual-microphone array, pickup distance up to 6 metres
• 10W high-power speaker: 90 dB intercom, 100 dB broadcast
• Codecs: G.711µ/a, G.722, G.726-32, G.729
• Audio processing: VAD, CNG, AEC, PLC, AJB, AGC, ANS

Access control

• Unlock via SIP call, QR code, HTTP API, or the Grandstream SecureAccess app
• 2-channel outputs for lock control and alarm linkage
• Standard relay plus anti-magnetic solid state relay (SSR)

Network and protocols

• 1 x 10/100 Mbps Ethernet port
• TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, SSH, SMTP, TFTP, NTP, STUN, SIMPLE
• TLS and SRTP for encrypted signalling and media
• TR-069 provisioning and GDMS cloud management

Power, physical and environmental

• PoE+: IEEE 802.3at Class 4
• DC input: 12–48V DC / 2A, 24W
• Dimensions: 200 x 120 x 40 mm
• Weight: 0.732 kg (1.551 kg packaged)
• Operating temperature: -40°C to 70°C
• Humidity: 10% to 90% non-condensing
• Ingress and impact protection: IP66, IK10 (metal surface, buttons and lens area)

Security

• 256-bit AES encryption
• 802.1x media access control
• TLS with Ed25519/X25519

Works with

• Grandstream GSC3560 — the audio-only version in the same housing
• Grandstream GSC3570 — indoor touchscreen station for viewing video and releasing the door
• Grandstream GSC3575 — larger indoor control station in black
• Grandstream GDS3710 — alternative video door system with built-in RFID reader
• All access control and door entry
• Grandstream IP video phones — answer door calls with video from a desk phone

Frequently asked questions

What is the difference between the GSC3565 and the GSC3560?

They share the same weatherproof housing, speaker, microphones, relays and network features. The GSC3565 adds a 1080p camera and QR code entry; the GSC3560 is audio only and instead offers AI-based noise suppression.

Where can I view the video from the door?

On a Grandstream indoor station such as the GSC3570 or GSC3575, on a Grandstream video desk phone, or on a mobile through the SecureAccess app. It is a standard SIP video endpoint, so most video-capable SIP clients will also work.

Will the camera cope with bright sunlight behind a visitor?

Yes. Wide dynamic range of up to 120 dB is specifically there to balance a dark face against a bright background, which is the usual problem on outward-facing doors.

How does QR code entry work?

You issue a code that the visitor holds up to the camera. It suits contractors, deliveries and short-term visitors because there is no fob to hand over or recover afterwards.

Can it be surface mounted on brick?

Yes — expansion bolts and screws are supplied in the box, along with a waterproof silicone plug for the cable entry and a ground wire.

Planning a door entry install and not sure whether you need video? Call 0333 242 1314 or email sales@clisecure.com and we will help you spec the right panel, lock and indoor station.
